| Bottom bracket: |
External Sealed Cartridge Bearing |
| Brakes: |
F: Tektro HD-M280 Hydraulic, 180mm Rotor | R: Tektro HD-M280 Hydraulic, 180mm Rotor |
| Brake levers: |
Tektro HD-M280 |
| Brake type: |
Hydraulic Disc Brake |
| Cassette: |
Tektro CS-M5100-11, 11-Speed, 11-50T,11 Speed |
| Chain: |
KMC X-11 Silver and Black |
| Chainset: |
Single |
| Colour: |
Dark Purple |
| Crankset: |
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing |
| Derailleur rear: |
Tektro RD-5100-L, Long Cage, Clutch |
| Fork: |
X-Fusion Sweep (27.5") Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset |
| Frame: |
Series 3 6061 Aluminum, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs |
| Grip: |
Marin MTN, Closed End |
| Handlebar: |
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5ş Up, 9ş Back |
| Handlebar stem: |
Marin 3D Forged Alloy, 35mm |
| Headset: |
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Hubs: |
F: Joytech D142TSE-B5, 141QR, 6-Bolt | R: Joytech D041-B15, 110x15mm, 6-Bolt |
| Rim: |
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
| Saddle: |
Marin Speed Concept |
| Season: |
2026 |
| Seat post: |
X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm |
| Shifters: |
Tektro, SL M5100-11R, 11-Speed |
| Shock: |
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom |
| Spokes: |
14g Black Stainless Steel |
| Tyres: |
Vee Tire Co. Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible |
| Wheel size: |
27.5" (650b) |
