| FRAME |
BIG.TRAIL TFS II, MAT aluminium, 29x2.4" max. WHS, 148x12 AST, BSA BBR, |
| SHOCK |
0, |
| FORK |
Suntour XCR34 2CR, Air, 140 STR, Tapered, lockout, 44mm fork offset, 29x2.4" max WHS, |
| BRAKE FRONT |
Shimano MT200, 2 piston |
| BRAKE REAR |
Shimano MT200, 2 piston |
| ROTOR FRONT |
Shimano RT10, 180mm |
| ROTOR REAR |
Shimano RT10, 180mm |
| CHAIN |
KMC xGlide, |
| CRANKSET |
Shimano CUES UT-400-1, 32t |
| CRANK LENGTH |
170mm on all sizes, |
| BB SET |
Shimano BB-UN101, 73mm |
| DERAILLEUR FRONT |
0, |
| DERAILLEUR REAR |
Shimano CUES U4000, |
| CASSETTE |
SunRace U9, CS-U980 9AZ, 11-46t, |
| PEDAL |
0, |
| GRIP |
MERIDA COMP TR, |
| HANDLEBAR |
MERIDA COMP TR II, MAT aluminium, 780 WHB, 35 RHB |
| STEM |
MERIDA COMP TR, MAT aluminium, 35 DSH, 0 ASD |
| STEM SIZE |
40 mm, |
| HEADSET |
Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing |
| HUB FRONT |
Shimano TC500-B, 110x15 WHF, 32 SPH, Centerlock |
| HUB REAR |
Shimano TC500-HM-B, 148x12 WHR, 32 SPH, Centerlock |
| RIM |
MERIDA COMP CC II, 25 IWR, MAT aluminium, tubeless ready |
| SADDLE |
MERIDA COMP SL, V-mount |
| SEAT CLAMP |
MERIDA EXPERT, |
| SEAT POST |
MERIDA COMP TR II, 34.9 DSP, 0 SSB, XSHORT: 150mm travel - SHORT, MID, LONG, XLONG: 170mm travel, |
| SHIFTER FRONT |
0, |
| SHIFTER REAR |
Shimano CUES U4000, |
| TYRE FRONT |
Kenda Regolith, 29x2.4", wire, |
| TYRE REAR |
Kenda Regolith, 29x2.4", wire, |
