| FRAME |
Series 3 6061 Aluminum, 26” Wheels (will fit 24"), 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs |
| FRONT SUSPENSION |
X-Fusion Velvet RLC 26", 130mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle |
| REAR SUSPENSION |
X-Fusion O2 Pro R, 190x45mm, Custom Tune, M8x25mm Hardware |
| RIMS |
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific |
| HUB, REAR |
Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Bod |
| HUB, FRONT |
Shimano HF-MT400B, 110x15mm, Centerlock |
| SPOKE, NIPPLES |
14g Stainless Steel |
| TIRES |
Vee Tire Co., Flow Snap 26x2.4", Tackee Compound, Wire Bead |
| DERAILLEUR, REAR |
Shimano RD-U6000, 11-Speed GS |
| SHIFT LEVER |
Shimano, SL-U6000-11R, 11-Speed |
| CRANKSET |
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring, Direct Mount Type |
| BOTTOM BRACKET |
External Sealed Cartridge Bearings |
| CHAIN |
Shimano LG-500 11-Speed |
| CASSETTE |
Shimano CS-LG400-11, 11-Speed, 11-50T |
| BRAKE, FRONT |
Tektro HD-M280 Hydraulic, 180mm Rotor |
| BRAKE, REAR |
Tektro HD-M280 Hydraulic, 180mm Rotor |
| BRAKE LEVERS |
Tektro HD-M280 |
| HANDLEBAR |
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4ş Up, 9ş Back |
| STEM |
Marin 3D Forged Alloy, 35mm |
| GRIPS |
Marin Dual Density |
| HEADSET |
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| SEATPOST |
X-Fusion Manic LC, 1x Composite Remote, 100mm |
| SADDLE |
Marin Speed Concept |
