| FRAME |
New Spyke 20 Frame, Updated Geometry and formed tubing, 6061 Alloy, 1 - 1/8" HT, IS Disc Tabs |
| FORK |
Zoom Steel suspension fork, 40mm travel, Coil |
| REAR SHOCK |
NIL |
| WHEELSET |
SURFACE Custom Wheelset |
| RIMS |
F: 20" Alloy Single Wall, 24H, Black; R: 20" Alloy Single Wall, 24H, Black |
| HUBS |
F: Joytech, 100x9 QR, 6 Bolt, 24H Front Hub; R: Joytech, 135x9 QR, 7-Speed, 6 Bolt, 24H Rear Hub |
| TYRES |
F: 20 x 2.35" Wanda P1226; R: 20 x 2.35" Wanda P1226 |
| CRANKSET |
SURFACE Alloy Crank, 127mm, 32T chainring, Black |
| REAR DERAILLEUR |
Shimano RD-TY500 Rear Derailleur, 6/7-speed |
| FRONT DERAILLEUR |
NIL |
| SHIFTER |
L: NIL, R: Shimano SL-RV300-7R Revo Shifter. 7-Speed |
| CASSETTE |
Shimano CS-HG200-7 Cassette, 7-speed, 12-28T |
| HANDLEBAR |
580mm x 25.4, 10°, H:15mm, Matt Black |
| STEM |
25.4mm E:60mm H:41mm 15° , Alloy Black |
| BRAKES |
F: Tektro MD-M280 Mechanical Disc Brake, R: Tektro MD-M280 Mechanical Disc Brake |
| ROTORS |
F: Tektro 160mm, 6-Bolt Rotor; R: Tektro 160mm, 6-Bolt Rotor |
| SEAT POST |
27.2mm x 250mm, Alloy Black |
| SADDLE |
SURFACE Kids Saddle |
| GRIP |
TPR Grips, Custom Colour, 125mm |
