| Frame: |
Aluminium, smooth welding, 9x135mm QR, 26" |
| Fork: |
SR Suntour XCR Air with light tune, 100mm, 9x100mm QR |
| Headset: |
External cup ball bearing, 1-1/8" EC34 |
| Grips: |
Norco Youth, 115mm |
| Handlebar: |
6061 alloy DB, 720mm, 20mm rise |
| Stem: |
Alloy, 45mm length, 31.8mm clamp |
| Seatpost: |
Norco alloy, 27.2mm, 250mm length |
| Saddle: |
Norco Jr XC, steel rail |
| Brakes: |
Tektro HD-M286, resin pads (front and rear) |
| Rotors: |
Tektro, 160mm, 6-bolt (front and rear) |
| Brake levers: |
Tektro HD-M286, hydraulic 2-finger Jr levers |
| Shifter: |
Shimano Cues SL-U4000, 9-speed |
| Rear derailleur: |
Shimano Cues RD-U4000, 9-speed, GS |
| Cassette: |
Shimano Cues CS-LG300-9, 11-46T, 9-speed |
| Chain: |
KMC Z9 |
| Crankset: |
Samox alloy 3pc, 152mm, 28T narrow-wide |
| Bottom bracket: |
Sealed bearing, ST 68mm |
| Hubs (front | rear): |
Formula DC-1420, 9x100mm QR, 28H, 6-bolt | Formula DC-1425, 10x135mm QR, HG, 32H, 6-bolt |
| Spokes: |
Stainless steel with brass nipples |
| Rims: |
Aluminium double wall, 28H, 26" MTB |
| Tyres: |
CST H-5183 MTB trail, 26x2.25", wire (front and rear) |
