| Frame: |
Aluminium, smooth welding, 12x148mm Boost, tapered HT |
| Fork: |
RockShox Judy Silver TK Air, 130mm, 51mm offset, 15x110mm Boost |
| Headset: |
Sealed cartridge bearings, tapered 1-1/8" - 1.5" |
| Grips: |
DDK lock-on, 139mm |
| Handlebar: |
Norco aluminium, 780mm, 30mm rise |
| Stem: |
Alloy, 40mm length, 31.8mm clamp |
| Seatpost: |
X-Fusion Manic LC dropper, 31.6mm, 130mm (S), 150mm (M), 170mm (L/XL/XXL) |
| Saddle: |
WTB Volt Sport, medium |
| Brakes: |
Shimano Deore BR-MT410, resin pads (front and rear) |
| Rotors (front | rear): |
Shimano RT-26, 180mm | 160mm, Center Lock |
| Brake levers: |
Shimano Deore BL-MT410 |
| Shifter: |
Shimano Deore SL-M6100-R, 12-speed |
| Rear derailleur: |
Shimano Deore RD-M6100, SGS, 12-speed |
| Cassette: |
Shimano Deore CS-M6100, 10-51T, 12-speed |
| Chain: |
KMC 12-speed |
| Crankset: |
Shimano Deore FC-MT512, 30T, 170mm (S-M), 175mm (L-XXL) |
| Bottom bracket: |
Shimano BB-MT501, BSA 68/73mm |
| Hubs (front | rear): |
Formula DC-511, 15x110mm, 32H, Center Lock | Formula DC-3248, 12x148mm Boost, HG, 32H, Center Lock |
| Spokes: |
Stainless steel, 14g |
| Rims: |
WTB ST TCS 2.0, 27mm ID, 32H |
| Tyres: |
Maxxis Forekaster, 29x2.35" (27.5x2.35" on S), wire (front and rear) |
